Description
●Single chamber inverted phase box structure.
●Low frequency of high, deep dive, with a wealth of flexibility and intensity, with a variety of full-range speakers to do loud sound field of language and music playback.
●Has excellent ultra-low frequency reduction capability for the sound reinforcement system for the full improvement of the bass and specially designed to reproduce the extreme bass that full of strong shock effect.
●With a wide frequency response and smooth frequency response curve in the work of high-power loud pressure environment remains the most perfect bass.
●Box with high-quality birch plywood, sprayed through the SGS environmental certification of water-based environmental protection paint.
|
Specifications:
|
|
RMS Power Handling
|
550W
|
|
Peak Power Handling
|
1200W
|
|
Unit
|
LF: 1x15” (380mm)/4”(100mm)voice coil
|
|
Frequency Response(±3 dB)
|
45Hz-120Hz
|
|
Sensitivity(1W @ 1M)
|
101dB
|
|
Maximum SPL
|
129dB Peak@1M
|
|
Nominal Impedance
|
8Ω
|
|
Crossover Frequency
|
120Hz
|
|
Input Connectors
|
2 x Neutrik NL4
|
|
Cabinet Type
|
18mm High Intensity Plywood
|
|
Unit Dimensions (W x H x D)
|
470mm (18.5”) x 690mm (27.2”) x 496mm (19.5”)
|
|
Package Dimensions (single unit per box)
|
560mm (22”) x 780mm (30.7”) x 585mm (23”)
|
|
Unit Net Weight
|
38.5kg (84.5Ibs)
|
|
Gross Weight(single unit per box)
|
42.6kg (94Ibs)
|
