Description
●Single chamber inverted phase box structure.
●Low frequency of high, deep dive, with a wealth of flexibility and intensity, with a variety of full-range speakers to do loud sound field of language and music playback.
●Has excellent ultra-low frequency reduction capability for the sound reinforcement system for the full improvement of the bass and specially designed to reproduce the extreme bass that full of strong shock effect.
●With a wide frequency response and smooth frequency response curve in the work of high-power loud pressure environment remains the most perfect bass.
●Box with high-quality birch plywood, sprayed through the SGS environmental certification of water-based environmental protection paint.
|
Specifications:
|
|
RMS Power Handling
|
750W
|
|
Peak Power Handling
|
1600W
|
|
Unit
|
LF: 1x18” (460mm)/3”(100mm)voice coil
|
|
Frequency Response(±3 dB)
|
40Hz-120Hz
|
|
Sensitivity(1W @ 1M)
|
101dB
|
|
Maximum SPL
|
130dB Peak@1M
|
|
Nominal Impedance
|
120Hz
|
|
Crossover Frequency
|
4kHz
|
|
Input Connectors
|
2 x Neutrik NL4
|
|
Cabinet Type
|
18mm High Intensity Plywood
|
|
Unit Dimensions (W x H x D)
|
561mm (22.1”) x 690mm (27.2”) x595mm (23.4”)
|
|
Package Dimensions (single unit per box)
|
650mm (26”) x 780mm (30.7”) x 680mm (26.8”)
|
|
Unit Net Weight
|
45kg (99.2Ibs)
|
|
Gross Weight(single unit per box)
|
49.5kg (109.2Ibs)
|
