Musical instrument Mixer Amplifier---

Application:Small performance,club,hotel,multifunction hall,music hall,wedding ceremony, Opening Ceremony,outdoor activites etc.

Description

1.Build-in 8 way mixer adjustment

2. Channel Balance Input with independent Volume adjustment,AUX and MIC switvh

3. 3 Mode : Reverb,Echo,Guitar effect

4.2 Master button:Volume and Menu.

5.With Bluetooth and USB/TF slot

6.Built-in Vocal elimination

7.Sub ultra low frequency adjustment 40Hz-150H with independent Volume adjustment

8. With Low Cut switch

9. 0/180° Phase adjustment

10.RCA Connector 2

11. Output Connectors:3 x NL4 Speakon 4pin.

12.Android mobile APP control

Technical Parameter

1.8Ω Stereo Power(1KHz): 2x500W+900W

2.4Ω Stereo Power: 2x720W+1100W

3.Frequency Response: 20Hz-20KHz ±0.5%

4.Signal Noise Ratio(dB): ≥102dB

5THD+N(rated power,1/8 /KHz)%: <0.05%

6.Input Sensitivity:1Vrms

7.Input Impedance:20kΩ balance/10 kΩ unbalance

8.Input Connectors:4 x 6.3 multipurpose interpolation+6.35 socket

9.Output Connectors:3 x NL4 Speakon 4pin.

10.Output Circuitry: CLASS AB

11.Power supply:AC110V-240V (50Hz-60Hz)

Dimensions(WxHxD):265x500x110mm

Packing Dimensions(WxHxD): mm

Net Weight:11.55kg

Gross Weight: kg
